T10-PRO
T10-PRO
T10-PRO integrated propulsion system, max thrust 25kg, recommended battery 14-18S, power assembly weight 1705±50g.
KV
100/80KV
Battery
14-18S
Dimensions
120*45
Carbon Tube
40mm
Total Weight
1705±50g
Features
Max Thrust: 25kg
Recommended Takeoff Weight: 9-12kg
Recommended Battery: 14-18S
Total Weight: 1705±50g
Applicable carbon tube size: 40mm
Operating Temperature: -20~40°C
Ingress Protection: IPX6
Rated Input Power: 1400W
Max Input Power: 5300W
Rated Thrust Efficiency: 8.1g/w
PWM Input Signal Level: 3.3V/5V
Throttle Pulse Width: 1050 ~1950μs
Compatible Signal Frequencies: 50~500 Hz
Max Allowable Voltage: 63/81V
Continuous Current Non-hermetic Ambient Temperature≤ 60℃: 45A
Maximum Current Non-hermetic Ambient Temperature≤ 60℃: 150A（10s)
Communication interface: CAN
KV Rating: 100/80KV
Copper Wire Size: High Temp Enameled Wire
Bearing: Waterproof
Total Weight: 343.30/481 .00g
Applications
AgricultureLogisticsIndustrial
