HV40
HV40
HV40 integrated propulsion system, max thrust 75kg, recommended battery 18S, power assembly weight 6050g.
KV
-
Battery
18S
Dimensions
153*100
Carbon Tube
60mm
Total Weight
6050g
Features
Max Thrust: 75kg
Recommended Takeoff Weight: 37kg
Recommended Battery: 18S
Total Weight: 6050g
Applicable carbon tube size: 60mm
Operating Temperature: -20~40°C
Ingress Protection: IPX6
Rated Input Power: 4500W
Max Input Power: 12.5kW
Rated Thrust Efficiency: 7.8g/w
PWM Input Signal Level: 3.3V/5V
Throttle Pulse Width: 1050 ~1950μs
Compatible Signal Frequencies: 50~500 Hz
Max Allowable Voltage: 81V
Continuous Current Non-hermetic Ambient Temperature≤ 60℃: 65A
Maximum Current Non-hermetic Ambient Temperature≤ 60℃: 250A（10s)
Communication interface: CAN
Overall Dimensions: 153*100
Diameter×Thread Pitch: 64*23 .0
Total Weight: 942.95g
Applications
AgricultureLogisticsIndustrial
