4125
4125
4125 brushless motor, KV 470KV, for 15/16/17inch propellers, max thrust -, weight 346±12g（With wire）.
KV
470KV KV
Weight
346±12g
Diameter
D49.5*51.6mm
Length
18±0.3mm
Features
Model: 4125
Motor Size: D49.5*51.6mm
Shaft-D: Ф6-0/-0.02mm
Shaft-L: 18±0.3mm
Wire Length: 90±3mm
Weight: 346±12g（With wire）
No Load Voltage: 20V
No load Current: 2.8±0.3A
No load Speed: 8930~9870RPM（470KV
Internal resistance: 16.2mΩ±5%
Working Voltage: 6-8S（3.7-4.2V/S）
KV Rating: 470KV
Propeller: 15/16/17inch
Max Thrust: 7kg
Flight Weight: 4-5kg
Applications
Fixed Wing UAVMappingLine Patrol
