4120
4120
4120 brushless motor, KV 610KV, for 14/15/16inch propellers, max thrust -, weight 294±10g（With wire）.
KV
610KV KV
Weight
294±10g
Diameter
D49.5*46.6mm
Length
18±0.3mm
Features
Model: 4120
Motor Size: D49.5*46.6mm
Shaft-D: Ф6-0/-0.02mm
Shaft-L: 18±0.3mm
Wire Length: 90±3mm
Weight: 294±10g（With wire）
No Load Voltage: 20V
No load Current: 3.8±0.4A
No load Speed: 11590~12810RPM（610KV）
Internal resistance: 13.7mΩ±5%
Working Voltage: 6-8S（3.7-4.2V/S）
KV Rating: 610KV
Propeller: 14/15/16inch
Max Thrust: 6kg
Flight Weight: 3-4kg
Applications
Fixed Wing UAVMappingLine Patrol
