K5215
K5215
5215 brushless motor, KV 440/500KV, for 15/13inch propellers, max thrust -, weight 333.1±10g（With wire）.
KV
440/500KV KV
Weight
333.1±10g
Diameter
D60.2*39mm
Length
26±0.3mm
Features
Model: 5215
Motor Size: D60.2*39mm
Shaft-D: Ф6 -0.02/-0.06mm
Shaft-L: 26±0.3mm
Wire Length: 400±5mm
Weight: 333.1±10g（With wire）
No Load Voltage: 10V
No load Current: 2.21±0.3A（440KV）/2.6±0.4A（500KV）
No load Speed: 4189~4630RPM（440KV) 4750~5250RPM（500KV)
Internal resistance: 24.27mΩ ±5% / 25.59mΩ ±5%
Working Voltage: 8-12S（440KV），（3.7-4.2V/S） 8-12S（500KV），（3.7-4.2V/S）
KV Rating: 440/500KV
Propeller: 15/13inch
Max Thrust: 7.8kg
Flight Weight: 12kg
Applications
FPV RacingFreestyleAerial Photography
