K4720
K4720
4720 brushless motor, KV 435KV, for 13/15inch propellers, max thrust -, weight 362.7±10g（With wire）.
KV
435KV KV
Weight
362.7±10g
Diameter
D56*46.15mm
Length
24.9±0.3mm
Features
Model: 4720
Motor Size: D56*46.15mm
Shaft-D: Ф6-0.02/-0.05mm
Shaft-L: 24.9±0.3mm
Wire Length: 350±5mm
Weight: 362.7±10g（With wire）
No Load Voltage: 20V
No load Current: 2.82±0.2A
No load Speed: 6612~7308RPM（435KV）
Internal resistance: 23.62mΩ±5%
Working Voltage: 8-12S（3.7-4.2V/S）
KV Rating: 435KV
Propeller: 13/15inch
Max Thrust: 10kg
Flight Weight: 14kg
Applications
FPV RacingFreestyleAerial Photography
