K4214
K4214
4214 brushless motor, KV 400/660KV, for 11/12/13/15-inch propellers, max thrust -, weight 210±10g（With wire）.
KV
400/660KV KV
Weight
210±10g
Diameter
D48.6*34.5mm
Length
26±0.3mm
Features
Model: 4214
Motor Size: D48.6*34.5mm
Shaft-D: Ф6 -0.02/-0.06mm
Shaft-L: 26±0.3mm
Wire Length: 400±5mm
Weight: 210±10g（With wire）
No Load Voltage: 10V
No load Current: 1.34±0.2A（400KV）/2.43±0.3A（660KV）
No load Speed: 4000~4420RPM（400KV） 86441~7119RPM（660KV）
Internal resistance: 61.65mΩ±5% / 35.1mΩ ±5%
Working Voltage: 8-12S（400KV），（3.7-4.2V/S） 4-8S（660KV），（3.7-4.2V/S）
KV Rating: 400/660KV
Propeller: 11/12/13/15-inch
Max Thrust: 5/7kg
Flight Weight: 8kg
Applications
FPV RacingFreestyleAerial Photography
